Description
Specifications
- Overall Length × Width × Height80.7″ × 27.9″ × 41.7″
- Wheelbase56.7″
- Curb Weight309 lbs
- Rated Load474 lbs
- Maximum Speed75 mph
- Brake Type (Front/Rear)Disc
- Brake Operation (Front/Rear)Hand brake
- Wheel Rims (Front/Rear)3.0×17 / 4.0×17
- Tire Size (Front/Rear)110/70-17 / 140/70-17
- Identification / TypeSingle-cylinder, oil-cooled engine with balancer
- Bore × Stroke65.5 × 66.2 mm
ENGINE
- Engine Capacity250 cc
- Compression Ratio9.2:1
- Maximum Power12 kW @ 7500 rpm
- Maximum Torque18 Nm @ 5500 rpm
- Minimum Idle Speed1600 rpm ± 100
- LubricationForced lubrication
- Lubricant TypeSJ 10W/40
- Clutch TypeWet multi-plate clutch
- Starting SystemElectric start
- IgnitionEFI
